VERTICAL MACHINING CENTER

HIGHT-SPEED VERTICAL MACHINING CENTER

STANDARD APPLICATION MODEL

MODEL	XYZ Travel (mm)	Spinle Nose to Table (mm)	Worktable (mm)	Max Load (Kg)	Spindle Taper	Spindle Speed (rpm)	Spindle Motor (kW)	XYZ Rapid Traverse (m/min)	Tool Capacity (T)
JF-V600	600/420/450	100-550	720*400	400	BBT40	12000	5.5	60/60/48	20
JF-V800	800/420/450	100-550	900*400	400	BBT40	12000	5.5	60/60/48	24
JF-V855	800/500/550	100-650	1000*500	800	BBT40	12000	11	48/48/36	24
JF-V1000	1000/600/600	100-700	1200*600	800	BBT40	12000	11	48/48/48	24
JF-V1200	1200/600/600	100-700	1400*600	800	BBT40	12000	11	48/48/48	24
JF-V1380	1300/800/700	150-850	1400*800	1200	BBT40	12000	11	30/30/30	24
JF-V1600	1600/600/600	100-700	1700*600	600	BBT40	12000	11	48/48/36	24
JF-V2000	2000/600/600	100-700	2100*600	600	BBT40	12000	11	48/48/36	24
JF-V2500	2500/750/710	50-760	2600*700	900	BBT40	12000	11	30/30/48	24

HEAVY-CUTTING VERTICAL MACHINING CENTER

HEAVY – DUTY APPLICATION MODEL

MODEL	XYZ Travel (mm)	Spinle Nose to Table (mm)	Worktable (mm)	Max Load (Kg)	Spindle Taper	Spindle Speed (rpm)	Spindle Motor (kW)	XYZ Rapid Traverse (m/min)	Tool Capacity (T)
JF-M855	800/500/550	100-650	1000*500	800	BBT40	12000	11	30/30/30	24
JF-M866	850/600/600	100-700	1000*550	800	BBT40	12000	15	36/36/36	24
JF-M1166	1100/600/600	100-700	1200*550	1000	BBT40	12000	15	36/36/36	24
JF-M1270	1200/700/700	100-700	1400*700	1200	BT50	6000	18.5	20/20/20	24
JF-M1270A	1200/700/700	130-830	1400*680	1000	BBT40	12000	15	20/20/20	24
JF-M1388	1300/800/800	100-900	1500*800	1200	BBT40	12000	15	20/20/20	24
JF-M1480	1400/800/700	100-800	1600*800	1500	BT50	6000	18.5	20/20/20	24
JF-M1688	1600/800/700	100-800	1800*800	1800	BT50	6000	18.5	20/20/20	24

For more details refer to catalog

● Unique structural design, combined with finite element analysis, super rigid structure, meet various high-speed and high-precision processing requirements.
● The whole machine cast iron adopts high synthetic cast iron (HT material), and is subjected to secondary annealing stress treatment to ensure the highest stability of the bed.
● The three axes adopt high-precision roller linear guide rails, and the direct high-speed spindle short nose design effectively improves the spindle cutting rigidity and reduces tool wear.
